Weber Power Control - User Interface Design for High End Slicing Machines

HMI Project Weber Power Control dashboard closeup on numbers
HMI Project Weber Power Control dashboard closeup
HMI Project Weber Power Control dashboard closeup on buttons

Touch-optimized user interface design for high end slicing machines.

The interface is designed modular. It can be adapted to different machine types. Heart of the interaction is the dynamic page layout. It enables constant supervision of the most important production key figures. The layout is responsive and adapts to new requirements after interaction. The dashboard – central monitoring and operation view – summarizes complex machine processes and displays them clearly. The depth of information can be extended by intuitive swipe gestures. So frequently used parameters can be quickly manipulated. In a workflow-oriented menu all production parameters are accessible grouped by either product processing steps or machine components. Further components are outsourced from the regular operation to an app-like view. It can be expanded by optional modules. Also an alternative skinning for a subcompanies smaller panel was provided. The frontend was developed using web technology to support a system wide uniform appearance and quick adaption to mobile devices.

Download project summary

The project was awarded the Red Dot Award: Communication Design 2013, the iF communication design award 2014 and it has been nominated for the German Design Award 2015 and the UX Design Award 2016.


Tasks

User Interface
User Experience
Infographics
HMI
Smart Parameter
Responsive
OPC UA

Tooling

Web Technology

Vimeo
External Video

We host our videos on Vimeo. When the videos load, a connection to Vimeo servers is established and cookies are set (possibly also from Vimeo).

Privacy

Features

HMI Project Weber Power Control panel and dashboard
HMI Project Weber Power Control dashboard
HMI Project Weber Power Control 3 dashboards mockup
HMI Project Weber Power Control interface with interaction illustrations
HMI Project Weber Power Control dashboard
HMI Project Weber Power Control dashboard

Harmonised with the industrial design of the panels

Production dashboard with most important KPIs

Adaptive design of widgets allows simultaneous operation and monitoring

Interaction concept with gestures

Adaptive dashboard with 3 active favorites functions

Adaptive dashboard with 6 active favorites functions
